MTM PF22.2 Foam Cannon

The best foam cannon on the market

This is hands down the best foam cannon in the market. How we sell this one though is a bit different than you’ll find from the factory, however. We take out the crappy zinc ¼” Plug and replace it with either a

PRIMA SS ¼” Plug

or

Mosmatic T304 ¼” Plug

. We also toss out the M22 Male to ¼” Male NPT fitting because all it does is confuse people. If you need to attach this to your pressure washer’s OE sprayer, and you need that part, you can find it here. But, do yourself a favor and just get a better sprayer. Heck, just get yourself a full

Upgrade Kit

 or

Accessory Packages

 that includes this foam cannon and everything else you need.

This is the new, upgraded MTM PF22.2. The main feature is that it doesn’t fall over now! The actual foam cannon hasn’t changed in design but the biggest and most requested change is to the bottle. It’s been redesigned to sit flat and not fall over when empty.

We also give you a choice of orifice nozzle that gets installed in the foam cannon. For the cheapo lower flow pressure washers, you’re going to want a 1.1mm orifice. For the higher flowing machines like

Kranzle

,

AR630

, and gas pressure washers, you want to go with a 1.25. If you’re having issues with your Kranzle over-amping, you may want to swap in a 1.5mm Foam Cannon Orifice.

 Specifications

MTM PF22.2 Foam Cannon
– Nickel Plated Brass – Single Cast Foam Cannon Body
– Two-way adjustable spray pattern
– 32oz Wide Bottom Bottle
– ¼” QD Plug Connection
– Min Pressure: 1,100 PSI – Max Pressure: 5,000 PSI
– Min Flow: 1.4 GPM – Max Flow: 5.3 GPM
– Max Temperature: 140°F
– Made in Italy
– Warranty: 60 days, for manufacturing defects
